- 1/2.8" progressive scan CMOS
- Up to 1920 × 1080 resolution
- Min. illumination:
Color: 0.05 Lux @(F1.5, AGC ON)
B/W: 0.01 Lux @(F1.5, AGC ON)
- 50× optical zoom, 16×digital zoom
- 120dB WDR, 3D DNR, HLC, BLC
- 24 VAC
- Support up to 1000 m laser distance
- Support H.265+/H.265 video compression
Camera | ||
---|---|---|
Image Sensor: | 1/2.8" HD progressive scan CMOS | |
Effective Pixels: | 1920(H)x1080(V) | |
Minimum Illumination: | Color: 0.05 Lux @(F1.8, AGC ON) B/W: 0.01 Lux @(F1.8, AGC ON) |
|
White Balance: | Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp | |
AGC: | Auto/Manual | |
BLC: | ON/OFF | |
HLC: | Support | |
Smart defog: | Support | |
WDR: | 120dB | |
Shutter Time: | 1/1 s to 1/30,000 s | |
Day& Night: | ICR | |
Digital Zoom: | 16× | |
Privacy Mask: | 24 programmable privacy masks | |
Auto Focus: | Auto / Semi-automatic / Manual |
Lens | ||
---|---|---|
Focal Length: | 6.6 mm to 330 mm, 50× Optical | |
Zoom Speed: | Approx. 4.5 s (optical lens, wide-tele) | |
Field of View: | Horizontal field of view: 41.3° to 1.1° (wide-tele) Vertical field of view: 23.6° to 0.6° (wide-tele) Diagonal field of view: 47.4° to 1.3° (wide-tele) |
|
Minimum Working Distance: | 10 mm to 1500 mm (wide-tele) | |
Aperture Range: | F1.8 to F5.5 |
Pan & Tilt | ||
---|---|---|
Pan Range: | 360°endless | |
Pan Speed: | Configurable, from 0.1°/s to 100°/s, Preset Speed: 50°/s | |
Tilt Range: | -90°-40° (Auto Flip ) | |
Tilt Speed: | Configurable, from 0.1°/s to 50°/s, Preset Speed: 100°/s | |
Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples | |
Number of Preset: | 300 | |
Patrol: | 8 patrols, up to 32 presets for each patrol | |
Pattern: | 4 pattern scans, record time over 10 minutes for each scan | |
Power-off Memory: | Support | |
Park Action: | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan | |
PTZ Position Display: | ON/OFF | |
Wiper: | Yes. Rain-sensing auto wiper |
Infrared | ||
---|---|---|
Laser Distance: | 1000 m |
Alarm | ||
---|---|---|
Alarm Input: | 7 Inputs | |
Alarm Output: | 2 |
Input & Output | ||
---|---|---|
CVBS Output: | 1.0V[p-p]/75Ω, NTSC (or PAL) composite, BNC | |
Audio Input: | 1-ch audio input | |
Audio Output: | 1-ch audio output |
Network | ||
---|---|---|
Ethernet: | 10Base-T / 100Base-TX, RJ45 connector (Fiber Connector Optional) | |
Max.Image Resolution: | 1920×1080 | |
Main Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), 50fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720), 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
|
Sub Stream: | 50Hz:25fps(704×576), 25fps(640×576), 25fps(320×288) 60Hz:30fps(704×480), 30fps(640×480), 30fps(320×240) |
|
Third Stream: | 50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) 60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288) |
|
Video Compression: | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
|
Audio Compression: | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM | |
Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour | |
Three-Stream: | Support | |
Storage: | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB | |
User/Host: | Up to 32 users, 3 levels: Administrator, Operator and User | |
Security Measures: | User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering |
Fiber Optical Interface (Available for Fiber dome) | ||
---|---|---|
Fiber Type: | 1 1000 M FC interface, TX1310/ RX1550 nm wavelength, 20 km transmission distance |
General | ||
---|---|---|
RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive | |
Power Supply: | 24V AC | |
Power Consumption: | Max.: 110 W | |
Working Temperature/Humidity: | Temperature: Outdoor: -40°C to 70°C (-40°F to 158°F) Humidity: ≤ 95% |
|
Protection Level: | IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection | |
Material: | Aluminum alloy ADC12 | |
Dimensions: | Φ360 mm × 508 mm (Φ 14.17" × 20.00") | |
Weight (approx.): | Approx. 13 kg (28.66 lb) |
