Features:
Technical Specifications:
|
Model |
BU-H20 |
|
Camera |
|
|
Image Sensor |
1/2.7" Smartsens CMOS |
|
Effective Pixels |
1936(H)×1096 (V) |
|
Electronic Shutter |
AUTO |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Manual |
|
BLC / HLC |
Support |
|
DNR |
2D/3D DNR |
|
Other |
Motion Detection, Privacy Mask, Flip, Mirror |
|
Encode |
|
|
Embedded Solution |
Mstar313E+SC2232 |
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
Main stream: 1080P@25fps, 720P@30fps |
|
Sub stream: VGA@ 360P/CIF@25fps, etc. |
|
|
Video Bitrates |
500Kbps - 6Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a |
|
IR Led |
|
|
IR Led |
18pcs SMD Array IR LEDs |
|
IR Distance |
20-30M IR Distance |
|
Lens |
|
|
Focal length |
2.8-12mm varifocal lens |
|
Zoom |
4X optical |
|
Optional Function |
|
|
POE, External Audio |
|
|
Network Services |
|
|
Protocol |
RTSP/DHCP/NTP/DST/FTP/SMTP |
|
P2P |
Yes |
|
Web |
IE , Firefox 32bit esr |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
General |
|
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 5 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
Package Contents:
* Color: White
* QTY/Carton: 24pcs
* GW/Carton: 16.0KG
* Carton SIZE: 640*326*400mm
