• Third-party network cameras supported
• Up to 12 Megapixels resolution recording
• Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160)
resolution
• 16/32-ch network cameras can be connected with
160M/256M incoming bandwidth
• Up to 4 SATA interfaces
• Support dual-os to ensure high reliablility of system
running
•Support various VCA detection alarm and VCA search
•Support H.265/H.264/MPEG4 video formats
Video/Audio Input | ||
---|---|---|
Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) | |
IP video input: | 32-ch |
Network | ||
---|---|---|
Remote connection: | 128 | |
Incoming bandwidth: | 256Mbps | |
Outgoing bandwidth: | 256Mbps |
Video/Audio Output | ||
---|---|---|
HDMI Output: | 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz | |
Recording Resolution: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
Audio Output: | 1-ch, RCA (Linear, 1kΩ) | |
Synchronous Playback: | 16-ch | |
VGA Output: | 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
Decoding | ||
---|---|---|
Capability: | 4-ch@8MP,16-ch@1080P | |
Live view / Playback: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Hard Disk | ||
---|---|---|
SATA: | 4 SATA interfaces for 4HDDs | |
Capacity: | Up to 6TB capacity for each HDD |
External Interface | ||
---|---|---|
Network Interface: | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces | |
Serial Interface: | RS-232; RS-485; | |
USB Interface: | Front panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0 |
|
Alarm In: | 16-ch | |
Alarm Out: | 4-ch |
General | ||
---|---|---|
Power Supply: | 100 to 240 VAC | |
Consumption(without hard disk and POE): | ≤20 W | |
Working Temperature: | -10 oC ~ +55 oC (+14 oF~ + 131 oF) | |
Working Humidity: | 10 % ~ 90 % | |
Chassis: | 19-inch rack-mounted 1.5U chassis | |
Dimensions: | 445 × 390 × 70 mm (17.5"× 15.3" × 2.8") | |
Weight(without HDD): | ≤ 5 Kg (11 lb) |
