Quick Overview
The Hikvision DS-7716NI-K4-16P is a 16 channel network video recorder with a wide array of features, including 16 PoE network interfaces, support for up to 4k (8MP) resolution recording and playback, H.264/H.264+/H.265/H.265+ codecs, and a dual OS design for reliability and failover redundancy.
This brand new NVR is designed to be cost-efficient, whilst still containing all of the benefits and features that are expected from Hikvision's latest generation of fantastic IP camera systems. It's perfect for those small security systems found in homes and shops.
The K Series NVRs also support Hikvision's Automatic Number Plate Recognition solutions. If ANPR is a requirement for you, we recommend pairing this NVR with the ANPR camera.
This NVR will accept any capacity hard drive (HDD) currently available. Any maximum capacity stated on the manufacturer’s documents is simply based upon the maximum HDD size that was available at the time of release/publication
Max. HDD Support - 40TB (4 x 10TB SATA Drive).
Max. Supported IP Cameras - 16
Max. Megabits Per Second - 160Mbps
Key Features
- Can connect up to 16 IP cameras
- Connectable to third-party cameras
- Up to 8MP recording resolution
- Supports live view and playback
- H.265+/H.265/H.264/MPEG4 video formats
- 4 SATA interfaces
- HDMI and VGA outputs
Additional Information
Weight |
5000.0000 |
Number of Channels |
16 |
Synchronous Playback |
16-ch |
Number of PoE Ports |
16 |
Incoming Bandwidth |
160 Mbps |
Outgoing Bandwidth |
160 Mbps |
Number of Bays |
4 |
Audio Input |
1-ch |
Audio Ouput |
1-ch |
Alarm I/O |
16/4 |
Front USB |
2 x USB 2.0 |
Rear USB |
1 x USB 3.0 |
Fan |
Yes |
RS232 |
Yes |
RS485 |
Yes |
ANR (Automatic Network Recover) |
Yes |
HDD Capacity Supplied |
0GB (Hard Disk Drives sold seperately to demand) |
Maximum Memory Capacity |
48TB |
Chassis |
1.5U |
Dimensions |
445 x 390 x 70mm |
Warranty |
2 Years |
Launch Date |
February 2017 |
